Product Description
The Eaton FD3080 is a Series C F Frame Molded Case Circuit Breaker. It is designed for use in various electrical applications. This circuit breaker provides overload protection through its fixed thermal and magnetic trip mechanism.
- 80 Amp current rating
- Rated for 600 Volt AC and 250 Volt DC
- 3 pole configuration
Product Highlights
This breaker is suitable for panelboards, switchboards, motor control centers, and busway systems. The design emphasizes reliability and compatibility with various electrical assemblies.
Product Information
Standard Information
-
Brand: Eaton
-
Manufacturer: Cutler-Hammer / Eaton
Technical Specifications
-
Catalog Number: FD3080
-
Weight: 4.5 lb
-
Width: 4.13 inches
-
Height: 6 inches
-
Length: 3.38 inches
-
Current Rating: 80 Amp
-
Voltage Rating: 600 VAC / 250 VDC
-
Frequency Rating: 50/60 Hz
-
Number of Poles: 3
-
Interrupt Rating: 35 kAIC
-
Trip Type: Fixed Thermal, Fixed Magnetic
-
Application: Electrical Assemblies, Panels & EOEM
