Product Description
The Eaton FD3060 is a molded case circuit breaker with a voltage rating of six hundred volts alternating current and two hundred fifty volts direct current. This circuit breaker is rated for sixty amps and is designed for use in high-performance applications.
- Three-pole configuration suitable for various applications.
- Fixed thermal and fixed magnetic trip types ensure reliable circuit protection.
- Interrupt rating of sixty-five kAIC at two hundred forty Vac and thirty-five kAIC at four hundred eighty Vac.
Product Highlights
The Eaton FD3060 is known for its durability and efficiency in protecting electrical circuits in panelboards, switchboards, and motor control centers.
Product Information
Standard Information
-
Manufacturer: Eaton
-
Manufacturer Part Number: FD3060
Technical Specifications
-
Type: Molded case circuit breaker
-
Frame: F
-
Phase: Three
-
Voltage Rating: 600 Vac / 250 Vdc
-
Amperage Rating: 60 A
-
Interrupt Rating: 65 kAIC at 240 Vac / 35 kAIC at 480 Vac
-
Wire Size: 14 to 1/0 AWG
-
Temperature Rating: 40 deg C
-
Dimensions: 3.38 x 4.13 x 6 inches
