Eaton FD2090L Eaton Series C complete molded case circuit breaker, F-frame, FD, Complete breaker, Fixed thermal, fixed magnetic trip type, Two-pole, 90A, 600 Vac, 250 Vdc

Product Description

The Eaton Series C molded case circuit breaker, Model FD2090L, is designed for use in panelboards, switchboards, motor control centers, and busway applications. This circuit breaker provides reliable protection for branch circuits and is suitable for systems operating at up to six hundred volts alternating current or two hundred fifty volts direct current.

• Current rating of ninety amperes
• Fixed thermal and magnetic trip functions
• Two-pole configuration with interrupt ratings of sixty-five kiloamperes at two hundred forty volts and thirty-five kiloamperes at four hundred eighty volts

Product Highlights

This breaker offers excellent user acceptance and meets or exceeds North American standards. The product is perfect for various applications, including electrical assemblies and panels.

Product Information

Standard Information

• Brand: Eaton
• Country of Origin: Dominican Republic

Technical Specifications

• Catalog Number: FD2090L
• Current Rating: 90 A
• Voltage Rating: 600 Vac, 250 Vdc
• Frequency Rating: 50/60 Hz
• Interrupt Rating: 65 kAIC at 240 Vac, 35 kAIC at 480 Vac
• Number of Poles: 2
• Frame: F
• Specifications: UL Listed
