Eaton FD2060 Circuit Breaker 600 VAC/250 VDC 60 A

Product Description

The Eaton FD2060 is a molded case circuit breaker designed for voltage applications of 600 volts alternating current and 250 volts direct current. This unit has a current rating of sixty amps and operates in both fifty and sixty hertz frequencies. It provides reliable protection in panelboards, switchboards, and motor control centers.

• Fixed thermal and magnetic trip settings
• Two poles offering reliable circuit interruption
• Rated interrupt capacity of thirty-five or sixty kiloamperes

Product Highlights

Designed for use in a variety of electrical applications, ensuring branch circuit protection and compliance with North American standards.

Product Information

Standard Information

• Manufacturer: Eaton
• Catalog Number: FD2060

Technical Specifications

• Type: Molded Case Circuit Breaker
• Frame: F
• Phase: 1
• Current Rating: 60 A
• Voltage Rating: 600 VAC / 250 VDC
• Number of Poles: 2
• Interrupt Rating: 35/65 kA
• Dimensions: 3.38 in L x 2.75 in W x 6 in H
