Eaton FD2030 Breaker Ckt Case Mld 600VAC/250VDC 30A

Product Description

Eaton FD2030 is a molded case circuit breaker designed for 600 VAC and 250 VDC applications. It features a 30 amp capacity and is ideal for panelboards, switchboards, motor control centers, and busway applications. These circuit breakers provide reliable branch circuit protection and meet North American standards for safety and performance.

• Two-pole configuration for versatile installation.
• Trip types include both fixed thermal and fixed magnetic ensuring enhanced protection.
• Designed to accommodate wire sizes from fourteen to one aught AWG.

Product Highlights

The Eaton FD2030 circuit breaker is part of the C series and offers features suitable for handling high-intensity discharge applications and reverse feed conditions. It has a interrupter rating of twenty-five kiloamperes.

Product Information

Standard Information

• Voltage Rating: 600 VAC/250 VDC
• Amperage Rating: 30 A

Technical Specifications

• Dimensions: 6 in H x 2.75 in W x 3.38 in D
• Frame Type: F
• Number of Poles: 2
• Frequency Rating: 50/60 Hz
• Interrupt Rating: 25 kA
• Temperature Rating: 40 deg C
• Connection Type: Load Lug
