EATON FD1045L C Series Type FD Molded Case Circuit Breaker 347 VAC/125 VDC 45 A

Product Description

EATON FD1045L is a C Series molded case circuit breaker. It is designed for use in panelboards, switchboards, and busway applications. This breaker provides reliable branch circuit protection. It meets North American standards and is used in systems up to six hundred VAC or two hundred fifty VDC with current ratings up to twenty-five hundred A.

• Type: FD
• Voltage Rating: 347 VAC/125 VDC
• Amperage Rating: 45 A

Product Highlights

This molded case circuit breaker features fixed thermal and magnetic trip functions. It is suitable for one-phase applications and designed to perform in temperatures up to forty degrees Celsius.

Product Information

Standard Information

• Manufacturer: Eaton
• Brand: EATON

Technical Specifications

• Dimensions: 3.38 x 1.38 x 6 in
• Connection Type: Line/Load
• Enclosure Type: NEMA AB1-1993
• Frequency Rating: 50/60 Hz
• Phase: 1 ph
• Material: Glass Polyester
• Series: C Series
• Temperature Rating: 40 deg C
• Interrupt Rating: 18 kAIC at 347 VAC/35 kAIC at 277 VAC
• Number of Poles: 1
• Trip Type: Fixed Thermal/Fixed Magnetic
