Eaton FAZ-D7/1-NA-SP FAZ-NA Branch Protector 7A D Curve

Product Description

The Eaton FAZ-D7/1-NA-SP is a FAZ branch protector, UL 489 industrial miniature circuit breaker and supplementary protector. Designed for high inrush current applications, it features screw terminals and a D curve. Rated at 7A, 10 kAIC, and 277V, it is a single-pole breaker operating at 50-60 Hz.

• UL 489 Industrial miniature circuit breaker
• Supplementary protector
• High levels of inrush current are expected

Product Highlights

The Eaton FAZ-D7/1-NA-SP is ideal for providing protection in many applications. A current limiting design provides fast short-circuit interruption, offering superior protection by reducing peak let-through current.

Product Information

Standard Information

• Brand: EATON
• Manufacturer Part Number: FAZ-D7/1-NA-SP
• Country of Origin: Spain

Technical Specifications

• Type: Branch protector
• Brand: Eaton
• Amperage: 7 Amp
• Standard: CSA,E2186,UL
• Trip Type: 10-20X/n, D-Curve
• Terminal Type: Standard Terminals
• Number of Poles: 1 Pole
• Catalog Number: FAZ-D7/1-NA-SP
• Country of Origin: Spain
• Made in USA: No
• Amperage Rating: 7 A
• Application: OtherGeneration - Renewable Energy - Alternative EnergyGeneration - Conventional Energy - Conventional EnergyDatacenters - IT Space: CI and Hyper ConvergedMarine Vessels and Equipment - Marine Vessels and Equipment - Other
• GTIN: 04015081636686
• Product Length/Depth: 1 in
• Product Height: 1 in
• Product Width: 3 in
• Product Type: Branch protector
• Terminals: Standard
• Category: Circuit Protection
• Circuit Breakers: Circuit Breakers
• Current Rating (Amps): 7A
• Manufacturer: Eaton Electrical
• Voltage Rating - AC: 277 V
• Series: FAZ-NA
• Voltage Rating - DC: 48 V
• Packaging: Bulk
• Actuator Type: Lever
• Part Status: Active
• Mounting Type: DIN Rail Mount
• Illumination: None
• Breaker Type: Thermal Magnetic
• Approval Agency: ABS, CSA C22.2 No 5, UL489, VDE
• UNSPSC Code: 39120000
• Characteristic: D curve
• Current Rating: 7 A
• For Use With: Circuit breakers
• Standards: UL 489
• Unit of Measure: EA
• Voltage Rating: 277/480 V
• Weight: 0.52 lb
