Eaton FAZ-D5/1-NA-SP 1-Pole 5 Amp Circuit Breaker

Product Description

The Eaton FAZ-D5/1-NA-SP is a 1-pole, 5 amp miniature circuit breaker designed for use in various electrical applications. This circuit breaker is rated for a maximum voltage of 277 volts and is ideal for branch circuits. It features a current limiting design that enhances safety by providing quick interruption of short circuits.

• 1-Pole Design for Compact Installations
• Operates at 5 Amps with 10 to 20X Thermal Magnetic Trip
• Rated for Use with Standard Terminals

Product Highlights

This circuit breaker meets CSA and UL standards, ensuring reliable performance in your electrical systems. It is suitable for applications requiring high safety levels, particularly in marine vessels and other critical environments.

Product Information

Standard Information

• Brand: Eaton
• Manufacturer Part Number: FAZ-D5/1-NA-SP

Technical Specifications

• Voltage Rating: 277/480 VAC
• Amperage Rating: 5 Amps
• Number of Poles: 1 Pole
• Standards/Approvals: CSA Std. C22.2 No. 235, UL 489
• Frequency Rating: 50/60 Hz
• Temperature Rating: 40 deg C
• Dimensions: 2.97 in W x 0.7 in D x 4.13 in H
• Trip Type: 10 to 20X/D-Curve Thermal Magnetic
