Eaton FAZ-D4/1-NA-SP ETN FAZ-D4/1-NA-SP 1P 4A D C

Product Description

The Eaton FAZ-D4/1-NA-SP is a UL 489 industrial miniature circuit breaker. It serves as a branch protector and is suitable for various circuit protection applications. This single-pole device has an amperage rating of four amps and operates at a voltage of two hundred seventy-seven volts. It has a short-circuit interrupting capability of ten kA and supports high inrush currents.

• Amperage Rating: 4A
• Voltage Rating: 277V
• Number of Poles: 1

Product Highlights

The Eaton FAZ series breakers are designed to provide rapid short-circuit interruption. They meet multiple safety standards and are ideal for marine, renewable energy, and conventional energy applications.

Product Information

Standard Information

• Brand: Eaton
• Manufacturer: Cutler-Hammer/Eaton

Technical Specifications

• Catalog Number: FAZ-D4/1-NA-SP
• Trip Type: 10-20X
• Frequency Rating: 50/60 Hz
• Country of Origin: Spain
• Material: Nylon
• Enclosure Type: IP20
• Operating Temperature: -40 to 75 degrees Celsius
• Standard: CSA C22.2 No. 235, UL 489
