Eaton FAZ-D30/1-SP Miniature Circuit Breaker, 30 Amp, 1 Pole, 277/480V

Product Description

Eaton's FAZ-D30/1-SP is a miniature circuit breaker designed to provide reliable protection for electrical circuits. This particular model is rated for thirty amps and is suitable for one pole applications. It operates at voltage levels up to two hundred seventy-seven or four hundred eighty volts. The compact size allows for easy installation in various settings such as electrical panels.

• Standard Current Limiting design for fast short-circuit interruption.
• Thermal Magnetic Trip technology enhances protection for sensitive equipment.
• UL and IEC compliance ensures safety in a range of applications.

Product Highlights

This circuit breaker is ideal for applications requiring efficient overcurrent protection. It is suitable for industrial, commercial, and renewable energy systems.

Product Information

Standard Information

• Manufacturer: Eaton
• Country of Origin: Romania

Technical Specifications

• Catalog Number: FAZ-D30/1-SP
• Amperage Rating: 30 A
• Voltage Rating: 277 VAC, 48 VDC
• Number of Poles: 1
• Enclosure Type: IP20
• Mounting Type: DIN Rail
• Temperature Rating: -40 to 75 deg C
• Trip Type: 10-20X/Thermal Magnetic
• Standards/Approvals: CSA Std. C22.2 No.235, UL 1077, IEC 60947-2
