Eaton FAZ-D25/3-NA FAZ-NA UL 489 MCB 25 A (Each)

Product Description

The Eaton FAZ-D25/3-NA is a UL 489 industrial miniature circuit breaker designed for branch protection. This device has a rated current of twenty-five amps and features a three-pole configuration. Its operating voltage is applicable for both three-phase and single-phase applications, supporting voltages up to four hundred eighty volts AC.

• Current limiting design to reduce detrimental let-through energy during a fault.
• Compatible with standard screw terminals, facilitating easy installation and maintenance.
• Trip characteristic ranges from ten to twenty times rated current for enhanced protection.

Product Highlights

The Eaton FAZ-D25/3-NA offers a reliable solution for protecting electrical circuits, ensuring safety in various applications, including datacenters, marine vessels, and renewable energy setups.

Product Information

Standard Information

• Brand: Eaton
• Manufacturer Part Number: FAZ-D25/3-NA

Technical Specifications

• Amperage Rating: 25 A
• Number of Poles: 3
• Voltage Rating: 277/480 VAC
• Interrupt Rating: 10 kA
• Temperature Rating: 40 °C
• Mounting Type: DIN Rail
• Connection Type: Screw/Standard Terminal
• Frequency Rating: 50/60 Hz
