Eaton FAZ-D20/3-NA Current Limiting Miniature Circuit Breaker 277/480 VAC 20 A 10 to 14 kA Interrupt 3 Poles 10 to 20X/D-Curve Thermal Magnetic

Product Description

The Eaton FAZ-D20/3-NA is a three-pole, 20 amp circuit breaker designed for 277/480 VAC applications. This breaker offers reliable protection for electrical circuits while featuring fast short-circuit interruption capabilities. It integrates a current limiting design which helps reduce the let-through energy during fault conditions. The FAZ-D20/3-NA is suitable for various applications including branch circuit device protection, renewable energy generation, and datacenters.

• Three-pole design with a 20 amp rating
• Trip Type: 10 to 20X/D-Curve Thermal Magnetic
• Standard terminals for easy connection

Product Highlights

The Eaton FAZ-D20/3-NA circuit breaker ensures safety and reliability in electrical systems. It features a thermal magnetic trip mechanism that provides overcurrent protection while being compatible with DIN rail mounting.

Product Information

Standard Information

• Manufacturer: Eaton
• Catalog Number: FAZ-D20/3-NA

Technical Specifications

• Voltage Rating: 277/480 VAC
• Amperage Rating: 20 A
• Number of Poles: 3
• Standards: CSA C22.2 No. 235, UL 489
• Frequency Rating: 50/60 Hz
• Dimensions: 2.97 in W x 2.1 in D x 4.13 in H
• Country of Origin: Spain
