Eaton FAZ-D20/2-NA Moeller Circuit Breaker 20 Amp 2 Pole 480/277 Volt

Product Description

The Eaton FAZ-D20/2-NA is a 20 Amp miniature circuit breaker designed for industrial applications. This model is a dual-rated UL and IEC circuit breaker, ideal for providing effective circuit protection. It features a current limiting design for fast short-circuit interruption.

• Two-pole configuration for versatile applications
• Designed for 277/480 Volt systems
• Complies with CSA and UL standards

Product Highlights

The FAZ-D20/2-NA offers significant protection against inrush currents, making it suitable for various applications including industrial and renewable energy sectors.

Product Information

Standard Information

• Manufacturer: Eaton
• Catalog Number: FAZ-D20/2-NA

Technical Specifications

• Amperage Rating: 20 Amp
• Voltage Rating: 480/277 VAC
• Approvals: UL 489, CSA Std. C22.2 No. 235
• Number of Poles: 2
• Trip Type: 10-20X
• Temperature Rating: -40 to 75 Deg C
• Enclosure Type: IP20
• Dimensions: 1.4 in L x 2.97 in W x 4.13 in H
