Eaton FAZ-D20/1-NA-SP Moeller 20 Amp Circuit Breaker

Product Description

Eaton FAZ-D20/1-NA-SP is a 20 Amp circuit breaker designed for reliable performance in various applications. This 1-pole miniature circuit breaker provides essential protection against overloads and short circuits, ensuring safety for your electrical system.

• UL listed and CSA certified
• Current limiting design for effective short-circuit interruption
• Supports DIN rail mounting for easy installation

Product Highlights

Designed for branch circuit protection, the Eaton FAZ-D20/1-NA-SP offers thermal magnetic trip functionality, accommodating diverse applications in both commercial and residential environments.

Product Information

Standard Information

• Manufacturer: Eaton
• Catalog Number: FAZ-D20/1-NA-SP

Technical Specifications

• Amperage Rating: 20 Amp
• Voltage Rating: 277/480 VAC, 48 VDC
• Frequency Rating: 50/60 Hz
• Number of Poles: 1
• Temperature Rating: -40 to 75 degrees Celsius
• Standards: UL 489, CSA C22.2 No. 235
• Trip Type: 10-20X/Thermal Magnetic
• Dimensions: 0.7 inches L x 2.97 inches W x 4.13 inches H
