Eaton FAZ-D2/1-SP FAZ UL 1077 Supplementary Protector 2 A (Single Package)

Product Description

Eaton FAZ-D2/1-SP is a UL 1077 supplementary protector (industrial miniature circuit breaker) rated 2 A designed for applications with high inrush current. It provides current-limiting short-circuit interruption with a D-curve thermal-magnetic trip (10-20X) and a 15 kA interrupting rating. The single-pole device is rated 277 VAC (50-60 Hz), features standard terminals and a handle actuator, and mounts on DIN rail.

• 2 A single-pole supplementary protector with D-curve thermal-magnetic trip (10-20X)
• 15 kA interrupting capacity and current-limiting design for fast short-circuit interruption
• Rated 277 VAC (50-60 Hz) and 48 VDC
• DIN-rail mounting, IP20 enclosure
• Accepts AWG wiring (product literature lists 18 to 4 AWG; some references show 18 to 8 AWG � see spec notes)

Product Highlights

Supplementary protector, 2 A, single pole, D curve, 15 kAIC, 277 VAC, DIN-rail, IP20

Product Information

Standard Information

• Brand: EATON
• Manufacturer Part Number: FAZ-D2/1-SP
• Country of Origin: Romania

Technical Specifications

• Brand: Eaton
• MPN: FAZ-D2/1-SP
• Series: FAZ
• Product Type: Supplementary protector / Industrial miniature circuit breaker (UL 1077)
• Amperage Rating: 2 A
• Voltage Rating: 277 VAC, 48 VDC
• Frequency: 50-60 Hz
• Interrupting Capacity: 15 kAIC
• Number of Poles: 1
• Trip Characteristic: D curve
• Trip Type: Thermal-magnetic (10-20x)
• Current Limiting: Yes
• Terminals: Standard terminals
• Actuator Type: Handle
• Mounting Type: DIN Rail
• Enclosure Rating: IP20
• Material: Nylon (housing)
• Wire Size: 18 to 4 AWG (see notes for alternate references)
• Operating Temperature: -40 to 75 �C
• Standards/Certifications: UL 1077; IEC 60947-2; CSA C22.2 No.235; CE; VDE; CCC; ABS
• Country of Origin: Romania
• GTIN: 04015081636839
• UPC: 01508163683
• Series Notes: Designed for high inrush current applications; D-curve suitable for highly inductive loads
