Eaton FAZ-D15/1-SP FAZ Supplementary Protector 15 A Q38

Product Description

The Eaton FAZ-D15/1-SP is a supplementary protector designed to provide optimal product quality and safety. This UL 1077 industrial miniature circuit breaker is suitable for supplementary protection with high levels of inrush current. It is a single-pole breaker with standard terminals and a D curve.

• UL 1077 Industrial miniature circuit breaker-supplementary protector
• Single package
• High levels of inrush current are expected

Product Highlights

Eaton’s FAZ series is DIN rail mountable and designed for use in control panel applications.

Product Information

Standard Information

• Brand: EATON
• Manufacturer Part Number: FAZ-D15/1-SP

Technical Specifications

• Product Name: Eaton FAZ supplementary protector
• Catalog Number: FAZ-D15/1-SP
• EAN: 4015081636907
• Product Length/Depth: 1 in
• Product Height: 1 in
• Product Width: 1 in
• Product Type: Supplementary protector
• Number of Poles: Single-pole
• Terminals: Standard
• Amperage Rating: 15 A
• Mounting Type: DIN Rail Mount
• UNSPSC Code: 39120000
• Series: FAZ Series
• Voltage Rating: 277 V, 480 V
• UPC Code: 4015081636907
• Actuator Type: Lever
• Type: Thermal/Magnetic
• Application: Datacenters - IT Space: CI and Hyper Converged, Generation - Conventional Energy - Conventional Energy, Generation - Renewable Energy - Alternative Energy, Marine Vessels and Equipment - Marine Vessels and Equipment - Other, Other
• Standards: UL 1077
• Current Rating: 15 A
• Characteristic: D curve
• Voltage Rating - AC: 277 V
• Voltage Rating - DC: 48 V
• Packaging: Bulk
• Part Status: Active
• Illumination: None
• Breaker Type: Thermal Magnetic
• Approval Agency: ABS, CCC, CSA C22.2 No 5, cURus, UL1077, VDE
• Interrupt rating: 10 kAIC
• Special features: Single Pack
• Frame: 40A
• Wire Size: 18 to 4 AWG, 18 to 8 AWG
• Connection Type: Screw
• Frequency Rating: 50/60
• Temperature Rating: -25 to 75
