Eaton FAZ-D10/1-SP ETN FAZ-D10/1-SP FAZ UL 1077 supp.

Product Description

The Eaton FAZ-D10/1-SP is a supplementary protector with a UL 1077 rating. It is designed for industrial use, providing essential overcurrent protection where branch circuit protection is not necessary. This device is suitable for applications with high levels of inrush current. It has a current interrupt rating of 15 kA and operates on a single pole with a voltage rating of 277 V. The trip type is 10-20X/n, and it functions optimally in frequencies ranging from fifty to sixty hertz.

• Single-pole design for compact installations
• Standard terminals for easy installation
• Built for high inrush current environments

Product Highlights

The Eaton FAZ-D10/1-SP provides reliable protection against overcurrent scenarios. It is made for standard terminal connections and features a temperature rating between -40 and 75 degrees Celsius. The unit is compatible with numerous applications across various industries, ensuring safety and performance.

Product Information

Standard Information

• Brand: Eaton
• Manufacturer Part Number: FAZ-D10/1-SP

Technical Specifications

• Amperage Rating: 10 Amp
• Voltage Rating: 277 VAC, 48 VDC
• Number of Poles: 1
• Standard: IEC 60947-2, UL 1077, CSA Std. C22.2 No. 235
• Country of Origin: Romania
• Material: Nylon
• Mounting Type: DIN Rail
• Temperature Rating: -40 to 75 degrees Celsius
• Trip Type: 10-20X/n
