Eaton FAZ-D10/1-NA-SP 1-Pole 10 Amp Circuit Breaker

Product Description

The Eaton FAZ-D10/1-NA-SP is a one-pole, ten amp miniature circuit breaker designed for protection in various electrical applications. This product is ideal for both residential and commercial settings.

• Current limiting design for fast short-circuit interruption.
• Built to meet UL 489 standards.
• Operates effectively in frequencies between 50 Hz and 60 Hz.

Product Highlights

With a compact size and robust design, this circuit breaker provides essential overcurrent protection. Its trip type is a thermal magnetic trip at a range of ten to twenty times the rated current.

Product Information

Standard Information

• Manufacturer: Eaton
• Catalog Number: FAZ-D10/1-NA-SP

Technical Specifications

• Voltage Rating: 480/277 VAC
• Amperage Rating: 10 A
• Number of Poles: 1
• Trip Type: 10-20X
• Dimensions: 0.7 inches L x 2.97 inches W x 4.13 inches H
• Enclosure Type: IP20
• Operating Temperature: -40 to 75 degrees Celsius
• Mounting Type: DIN Rail
