Eaton FAZ-C8/3-NA Circuit Breaker 8A 3 Pole

Product Description

The EATON FAZ-C8/3-NA is a current limiting miniature circuit breaker designed for overcurrent and short-circuit protection in industrial and commercial electrical distribution systems. Rated at 8 amps with a 3-pole configuration, it uses a Type C trip curve, making it well suited for loads with moderate inrush currents such as motors, transformers, and general control circuits. Licensed electricians and electrical contractors install this device in panelboards and control enclosures where reliable branch circuit protection is required.

This circuit breaker is intended for use in North American electrical installations where compact, high-performance branch protection is needed. The FAZ series is commonly found in industrial control panels, machinery enclosures, and commercial distribution boards. Its current limiting characteristic helps reduce let-through energy during fault conditions, protecting downstream components and wiring.

Key Features

• 8 amp rated current with Type C trip curve for moderate inrush load applications
• 3-pole design provides simultaneous disconnection of all three phases
• Current limiting action reduces fault let-through energy to protect downstream equipment
• Miniature form factor suits compact panelboards and control enclosures
• North America market variant designed to meet applicable UL and CSA requirements

Compatibility

Designed as an OEM-style miniature circuit breaker replacement for 3-pole branch circuit protection applications in North American industrial and commercial control panels.

Installation Notes

Installation must be performed by a qualified electrician in accordance with the National Electrical Code (NEC) and any applicable local codes. De-energize and lockout the panel or enclosure before installing or removing the breaker. Verify that the breaker rating matches the circuit conductor ampacity and load requirements before energizing. Do not modify the device or attempt to use it outside its marked ratings.

Technical Specifications

• Rated Current: 8 amps
• Number of Poles: 3
• Trip Curve: Type C
• Type: Current Limiting Miniature Circuit Breaker
• Market: North America (NA)
• UPC: 01508102122

Standard Information

• Brand: EATON
• Manufacturer Part Number: FAZ-C8/3-NA
