Eaton FAZ-C7/1-NA-SP Miniature Circuit Breaker 7A 1P

Product Description

The EATON FAZ-C7/1-NA-SP is a single-pole miniature circuit breaker rated at 7 amps with a Type C trip curve. Type C breakers are designed for circuits with moderate inrush current, making them well suited for motor loads, transformers, and control panel applications. This breaker provides overcurrent and short-circuit protection in a compact DIN-rail-mount form factor. It is installed by licensed electricians working on residential, commercial, or light industrial electrical distribution systems where reliable branch circuit protection is required.

This circuit breaker is appropriate for use in load centers, control panels, and electrical enclosures that require branch or supplementary circuit protection. The Type C trip characteristic accommodates startup surges common in motor-driven and inductive load circuits. Its compact footprint suits applications where panel space is limited and precise overcurrent protection is needed at the 7-amp rating.

Key Features

• Type C trip curve rated for moderate inrush current loads such as motors and transformers
• Single-pole configuration for individual branch circuit protection
• 7-amp continuous current rating
• DIN-rail-mount design for efficient panel installation
• FAZ series compact form factor suitable for space-constrained enclosures

Compatibility

Designed as an OEM-style replacement or new-installation miniature circuit breaker for DIN-rail-compatible electrical panels and control enclosures requiring single-pole Type C overcurrent protection.

Installation Notes

Installation should be performed by a licensed electrician in accordance with the National Electrical Code (NEC) and all applicable local codes. De-energize and lock out the panel before installing or replacing any circuit breaker. Verify that the DIN rail and enclosure are rated for the breaker series prior to mounting. Do not exceed the breaker's continuous current rating when sizing the protected circuit.

Technical Specifications

• Current Rating: 7 amps
• Poles: 1
• Trip Curve: Type C
• Mounting: DIN Rail
• UPC: 01508163631

Standard Information

• Brand: EATON
• Manufacturer Part Number: FAZ-C7/1-NA-SP
