Eaton FAZ-C4/2-NA 2-Pole 4 Amp Circuit Breaker

Product Description

The Eaton FAZ-C4/2-NA is a two-pole, four amp circuit breaker designed to protect electrical circuits in various applications. This industrial-grade circuit breaker conforms to UL 489 standards and is suitable for supplementary protection in branch circuits. It features a current limiting design, which provides fast short-circuit interruption, enhancing safety and reliability in electrical systems.

• Voltage Rating: 277/480 Volt
• Interrupt Rating: 10 kAIC and 14 kAIC
• Frequency Rating: 50-60 Hz

Product Highlights

Ideal for branch circuit protection, the Eaton FAZ-C4/2-NA circuit breaker is effective in applications ranging from conventional energy generation to marine vessels. It operates on a screw terminal connection, making installation straightforward.

Product Information

Standard Information

• Catalog Number: FAZ-C4/2-NA
• Manufacturer: Eaton
• Brand: Eaton
• Country of Origin: Spain
• Made in USA: No

Technical Specifications

• Type: Branch protector
• Amperage Rating: 4 Amp
• Number of Poles: 2
• Trip Type: 5-10X /n, C-Curve
• Interrupt Rating: 10 kAIC, 14 kAIC
• Standard: CSA Std. C22.2 No. 235, UL 489
• Voltage Rating: 277/480 Volt
• Temperature Rating: 40°C
• Connection Type: Standard terminals
