Eaton FAZ-C4/1-SP Miniature circuit breaker 4 Amp (1 Pole)

Product Description

The Eaton FAZ-C4/1-SP is a supplementary overcurrent protector (industrial miniature circuit breaker) rated 4 A and 277 V, intended for DIN-rail installation. It features a current-limiting design with a 15 kA interrupt rating and a 5-10X thermal-magnetic (C-curve) trip characteristic for medium inrush applications, and operates at 50-60 Hz within a -40 to 75 deg C range.

• 4 A amperage, single-pole supplementary protector with 15 kA interrupt rating and C-curve (5-10X) thermal-magnetic trip
• DIN rail mounting, IP20 enclosure, nylon housing, handle actuator; accepts 18 to 4 AWG (power) and 18 to 8 AWG wiring
• Rated for 277 V AC (50-60 Hz); operating temperature -40 to 75 deg C; dimensions 3 x 0.69 x 1 in

Product Highlights

Supplementary 1-pole DIN-rail breaker, 4 A, 277 V, 15 kA interrupt, IP20, -40 to 75 deg C

Product Information

Standard Information

• Brand: EATON
• Manufacturer Part Number: FAZ-C4/1-SP
• Country of Origin: Romania

Technical Specifications

• Brand: Eaton
• Manufacturer Part Number: FAZ-C4/1-SP
• Product Type: Supplementary protector / Industrial miniature circuit breaker
• Amperage Rating: 4 A
• Number of Poles: 1
• Voltage Rating: 277 V
• Frequency Rating: 50-60 Hz
• Interrupt Rating: 15 kAIC
• Trip Type: 5-10X / Thermal magnetic (C-curve)
• Mounting Type: DIN Rail
• Enclosure Rating: IP20
• Housing Material: Nylon
• Actuator Type: Handle
• Wire Size: 18 to 4 AWG (power); 18 to 8 AWG
• Dimensions: 3 x 0.69 x 1 in
• Operating Temperature: -40 to 75 deg C
• Standards/Certifications: CSA C22.2 No.235; UL 1077; IEC 60947-2
• Country of Origin: Romania
• Special Features: Current limiting design; trip-free design; red/green contact position indicator; captive screws
• Application: Supplementary overcurrent protection for control circuits, lighting, transformers, pilot devices, data centers, marine and generation applications
