Eaton FAZ-C4/1-NA-SP Current Limiting Supplementary Protector 4A 1 Pole 277/480V

Product Description

Eaton FAZ-C4/1-NA-SP is a current limiting supplementary protector rated at four amps. This single pole circuit breaker is designed for applications requiring a high level of protection against overcurrent conditions. It operates at 277/480 volts and features a trip type rating of 5-10X. The device provides fast short-circuit interruption, which protects circuits from damaging currents.

• Current limiting design
• Four amps rating
• Single pole configuration

Product Highlights

This circuit breaker is suitable for marine vessels, data centers, and various energy generation applications. It combines robust protection with reliable operation.

Product Information

Standard Information

• Brand: Eaton
• MPN: FAZ-C4/1-NA-SP

Technical Specifications

• Voltage Rating: 277/480 VAC
• Amperage Rating: 4 A
• Number of Poles: 1
• Frequency Rating: 50/60 Hz
• Interrupt Rating: 10 kAIC
• Dimensions: 0.7 in L x 2.97 in W x 4.13 in H
• Enclosure Type: IP20
• Material: Nylon
