Eaton FAZ-C32/1-NA-SP Miniature Circuit Breaker 32 A 277 V (Single package) FAZ-C32/1-NA-SP

Product Description

Eaton FAZ-C32/1-NA-SP is a current-limiting miniature circuit breaker rated 32 A and 277 V for single-pole branch protection. It is dual rated to UL and IEC standards, offers a 10 kA interrupting rating, and uses a thermal-magnetic 5-10X/C-curve trip. The device is DIN rail mountable with a toggle actuator, screw terminals and accepts 18 to 6 AWG conductors for industrial, datacenter, renewable energy, marine and general branch-circuit applications.

• Dual rated to UL and IEC standards with UL 1053 residual current circuit breaker capability
• Current-limiting design with 10 kA interrupting rating and 5-10X thermal-magnetic (C-curve) trip
• Single-pole 32 A, 277 V device with DIN rail mounting, toggle actuator and screw terminals (accepts 18 to 6 AWG)

Product Highlights

32 A single-pole current-limiting breaker, 10 kA interrupting rating, DIN rail mountable for branch circuit protection

Product Information

Standard Information

• Brand: EATON
• Manufacturer Part Number: FAZ-C32/1-NA-SP
• Country of Origin: Spain

Technical Specifications

• Manufacturer: Eaton
• Brand: Eaton
• Manufacturer Part Number: FAZ-C32/1-NA-SP
• Series: FAZ-NA
• Type: Current limiting miniature circuit breaker
• Item Type: Branch protector / supplementary protector
• Amperage Rating: 32 A
• Voltage Rating: 277 V
• Number of Poles: 1
• Frequency Rating: 50-60 Hz
• Interrupting Rating: 10 kAIC
• Trip Type: 5-10X (thermal-magnetic, C-curve)
• Trip Range: 5 to 10X
• Actuator Type: Toggle
• Connection Type: Screw/standard terminal
• Terminals: Screw
• Mounting Type: DIN rail
• Wire Size: 18 to 6 AWG (top); 18 to 10 AWG (bottom)
• Operating Temperature: 40 deg C ambient
• Country of Origin: Spain
• Certifications/Standards: UL 489; CSA C22.2 No. 235; IEC 60947-2; UL 1053; CE; CCC; ABS; VDE
• Applications: Branch circuit device protection, motor control, computers and UPS equipment, renewable and conventional energy, datacenters, IT space, marine vessels, industrial equipment
• Special Features: Single package; current-limiting design; contact position indicator; captive screws; field-installable shunt trip and auxiliary switch; possibility to seal toggle
