Eaton FAZ-C30/3-NA ETN FAZ-C30/3-NA FAZ-NA UL 489 MCB 30A C Curve

Product Description

Eaton FAZ-C30/3-NA is a UL 489 industrial miniature circuit breaker, designed for branch protection. This circuit breaker is suitable for medium levels of inrush current and operates at thirty amperes with a voltage rating of two hundred seventy-seven to four hundred eighty volts. It features three poles and provides trip protection with a rating of 5-10 times the normal current. The FAZ-C30/3-NA integrates screw terminals for easy installation.

• Current limiting design for enhanced short-circuit protection
• Trip-free operation that cannot be bypassed
• Field installable shunt trip option available

Product Highlights

This circuit breaker is essential for protective measures in a variety of electrical applications. It ensures safety for personnel and equipment with its robust design.

Product Information

Standard Information

• Catalog Number: FAZ-C30/3-NA
• Manufacturer: Eaton

Technical Specifications

• Amperage Rating: 30 A
• Voltage Rating: 277/480 V
• Frequency Rating: 50-60 Hz
• Interrupt Rating: 14 kAIC
• Number of Poles: 3
• Trip Type: 5-10X
• Country of Origin: Spain
• Standard: CSA Std. C22.2 No. 235, UL 489
