Eaton FAZ-C3/2-NA FAZ Branch Protector 3 A

Product Description

The Eaton FAZ-C3/2-NA is a branch protector and UL 489 industrial miniature circuit breaker. Designed as a supplementary protector, it is suitable for applications where medium levels of inrush current are expected. This two-pole breaker is rated at 3A and 277/480 V, with a C curve and screw terminals.

• Suitable for branch circuit device protection
• Current limiting design
• DIN Rail Mount

Product Highlights

The Eaton FAZ-C3/2-NA provides reliable branch circuit protection for industrial applications, with a design optimized for medium inrush currents.

Product Information

Standard Information

• Brand: EATON
• Manufacturer Part Number: FAZ-C3/2-NA

Technical Specifications

• Product Name: Eaton FAZ branch protector
• Catalog Number: FAZ-C3/2-NA
• EAN: 4015081020379
• Product Length/Depth: 1.4 in
• Product Height: 4.13 in
• Product Width: 2.97 in
• Certifications: UL 489
• Catalog Notes: Positioned for medium inrush startup currents to provide protection for small transformers and pilot devices.
• Product Type: Branch protector
• Number of poles: 2
• Terminals: Screw
• Type: Thermal/Magnetic
• Amperage Rating: 3 A
• Circuit protection: C curve
• Frequency rating: 50-60 Hz
• Interrupt rating: 14 kAIC
• Trip Type: 5-10X /n
• Voltage rating: 277/480V
• Application: Suitable for applications where medium levels of inrush current are expected
• Series: FAZ Series
• Amperage: 3A
• Voltage: 480Y/277VAC, 96VDC
• Poles: 2
• Phase: 1
• AIC Rating: 10kA @ 480Y/277VAC, 10kA @ 96VDC
• Mounting Style: DIN Rail
• Terminal Type: Box Lugs
• For Use With: DIN Rail Systems, Industrial Control Panels
• Trip Technology: Thermal Magnetic
• Trip Function Code: LI
• Trip Function: Long-Time, Instantaneous
• Trip Curve: C
• Trip Adjustability: Fixed
• Wire Gauge: 18-6 AWG (1 wire), 18-10 AWG (2 wires)
• Max Wire: 6 AWG
• Min Wire: 18 AWG
• Available Options: Auxiliary Switch, Shunt Trip, Undervoltage Release, Lockout Attachment, Busbar System
• Standards: CSA C22.2 No. 5, IEC 60947-2, UL 489
• Approval: ABS, CE, CSA, DNV, IEC, Lloyd's, RoHS, UL, VDE
• Temp Rating: -40C to 75C
• Construction Features: Current Limiting, HACR Rated, Reverse Feed, Trip-Free Mechanism, Visual Trip Indicator, RoHS Compliant
• Manufacturer: Eaton - Cutler Hammer
• Mounting Type: DIN Rail Mount
• UNSPSC Code: 39120000
• Unit of Measure: EA
• UPC Code: 4015081020379
• Actuator Type: Toggle
• Approvals: CSA Std. C22.2 No. 235, UL 489
• Current Rating: 3 A
• Characteristic: C Curve
• Product Series: FAZ
• Family Series: Eaton Circuit Breakers, FAZ Series
• Max Voltage: 480 VAC, 96 VDC
• Trip Unit: Fixed Thermal / Fixed Magnetic
• Mounting: DIN Rail
• Neutral Pole: No
• Auxiliary Switch: Optional
• Shunt Trip: Optional
• Undervoltage Release: No
• Alarm Switch: Optional
• UL Standard: 489
