Eaton FAZ-C20/2-NA 2-Pole 20 Amp Circuit Breaker

Product Description

The Eaton FAZ-C20/2-NA is a 2-pole, 20 Amp miniature circuit breaker designed for branch protection in industrial and commercial applications. It is ideal for use where medium levels of inrush current are expected. This circuit breaker is UL listed under standard 489, ensuring reliability and safety.

• Rated for voltages of 277/480 V
• Interrupt ratings of 10 kAIC
• Designed for DIN rail mounting

Product Highlights

This breaker features a thermal magnetic trip type and operates in temperatures ranging from -25 to 75 degrees Celsius. It is suitable for various applications, including renewable energy generation and marine equipment.

Product Information

Standard Information

• Manufacturer: Eaton
• MPN: FAZ-C20/2-NA

Technical Specifications

• Voltage Rating: 277/480 V
• Amperage Rating: 20 A
• Number of Poles: 2
• Frequency Rating: 50/60 Hz
• Trip Type: 5-10X
• Temperature Rating: -25 to 75 degrees C
• Interrupt Rating: 10 kAIC
• Mounting Type: DIN Rail
