Eaton FAZ-C20/1-SP FAZ UL 1077 Supplementary Protector 20 Amp 1 Pole 277 V

Product Description

The Eaton FAZ-C20/1-SP is a supplementary protector with UL 1077 certification. This industrial miniature circuit breaker is designed for protection in various applications. The product can handle a 20 Amp current load and operates at a voltage rating of two hundred seventy-seven volts. It is ideal for controlling the inrush current in multiple electrical systems.

• 20 Amp with C-Curve trip type
• Operating frequency of 50 to 60 Hz
• Single pole with standard terminal connections

Product Highlights

This product is suitable for protection in renewable energy systems, business equipment, and lighting applications.

Product Information

Standard Information

• Manufacturer: Eaton
• UPC: 01508163764

Technical Specifications

• Catalog Number: FAZ-C20/1-SP
• Amperage Rating: 20 Amp
• Voltage Rating: 277 VAC, 48 VDC
• Trip Type: 5-10X/n, C-Curve
• Interrupt Rating: 15 kAIC
• Number of Poles: 1
• Frequency Rating: 50-60 Hz
• Enclosure: IP20
