Eaton FAZ-C2/3-NA Current Limiting Miniature Circuit Breaker, 277/480 V, 2 A, 10 kA Interrupt, 3 Poles, 5-10X/C-Curve/Thermal Magnetic Trip

Product Description

The Eaton FAZ-C2/3-NA is a current limiting miniature circuit breaker rated at 277/480 volts and 2 amps. Designed for branch circuit protection, this breaker meets UL 489 standards and provides reliable performance in various applications.

• Rated at 2 amps, suitable for medium inrush current.
• Features three poles and trip characteristics of 5-10X with a thermal magnetic trip mechanism.
• Interrupt ratings of 10 kA and 14 kA ensure safe operation.

Product Highlights

These circuit breakers are ideal for protecting circuits in industrial and commercial settings, ensuring safety and reliability.

Product Information

Standard Information

• Brand: Eaton
• Manufacturer: Cutler-Hammer / Eaton

Technical Specifications

• Catalog Number: FAZ-C2/3-NA
• Voltage Rating: 277/480 V
• Amperage Rating: 2 A
• Frequency Rating: 50-60 Hz
• Number of Poles: 3
• Trip Type: 5-10X/C-Curve/Thermal Magnetic
• Interrupt Rating: 10 kA, 14 kA
• Temperature Rating: 40 deg C
• Mounting Type: DIN Rail
