Eaton FAZ-C2/2 Current Limiting Circuit Breaker

Product Description

The EATON FAZ-C2/2 is a current limiting miniature circuit breaker designed for overcurrent and short-circuit protection in low-voltage electrical distribution systems. This 2-pole breaker carries a C-curve trip characteristic, making it suited for loads with moderate inrush current such as lighting circuits, small motors, and general branch circuit applications. Licensed electricians and electrical contractors install this device in panelboards and distribution enclosures where reliable, fast fault interruption is required.

The FAZ-C2/2 is applied in residential, light commercial, and industrial branch circuit protection scenarios. Its current limiting capability reduces the let-through energy during a fault event, helping protect downstream wiring and equipment. The 2-pole configuration handles single-phase branch circuits requiring simultaneous disconnection of both conductors.

Key Features

• Current limiting design reduces fault energy let-through to downstream components
• C-curve trip characteristic suited for moderate inrush loads including lighting and small motors
• 2-pole configuration provides simultaneous disconnection of both circuit conductors
• Miniature circuit breaker form factor fits standard DIN rail or panel mount installations

Compatibility

Designed as an OEM-style replacement or new-installation miniature circuit breaker for use in standard low-voltage electrical distribution panels and enclosures accepting DIN rail mounted devices.

Installation Notes

Installation must be performed by a licensed electrician in accordance with the National Electrical Code (NEC) and all applicable local codes. De-energize the panel and verify absence of voltage before handling or installing the breaker. Ensure the panelboard or enclosure is rated to accept the breaker frame size and interrupting rating. Do not install or modify under load.

Technical Specifications

• Poles: 2
• Trip Curve: C
• UPC: 01508278748

Standard Information

• Brand: EATON
• Manufacturer Part Number: FAZ-C2/2
