Eaton FAZ-C2/1-SP FAZ UL 1077 Supp. 1

Product Description

Eaton FAZ-C2/1-SP is a supplementary protector designed for circuit protection. This model features a single pole and is ideal for applications where medium inrush currents are present. It operates at a voltage of two hundred seventy-seven volts and has an interrupt rating of fifteen kA.

• Single-pole design
• Thermal magnetic trip type
• Suitable for industrial and commercial applications

Product Highlights

This product offers reliable overcurrent protection where branch circuit protection is not required or provided by a separate device. The current limiting design ensures fast short circuit interruption, enhancing safety.

Product Information

Standard Information

• Brand: Eaton
• Manufacturer Part Number: FAZ-C2/1-SP

Technical Specifications

• Voltage Rating: 277 VAC, 48 VDC
• Amperage Rating: 2 A
• Number of Poles: 1
• Interrupt Rating: 15 kAIC
• Temperature Rating: -40 to 75 degrees C
• Mounting Type: DIN Rail
• Trip Type: Thermal Magnetic
• Frequency Rating: 50/60 Hz
