Eaton FAZ-C16/1-NA-SP Supplementary Protector 16A 1P

Product Description

The EATON FAZ-C16/1-NA-SP is a single-pole supplementary protector rated at 16 amps, designed to provide overcurrent protection for individual branch circuits and equipment loads. Supplementary protectors of this type are not intended to serve as branch circuit protection on their own but are used downstream of a primary breaker to protect specific loads or control circuits. The C-curve trip characteristic makes this unit suited for resistive and moderate inductive loads where normal inrush currents are present. Licensed electricians and panel technicians are the primary installers.

This supplementary protector is commonly used in industrial control panels, machinery enclosures, and commercial electrical equipment assemblies where space-efficient, DIN-rail-mountable overcurrent protection is required. The FAZ series is a compact solution appropriate for protecting motors, transformers, and general-purpose control circuits in residential, commercial, and light industrial applications.

Key Features

• 16 amp continuous current rating with C-curve trip characteristic for moderate inrush tolerance
• Single-pole configuration for individual circuit protection
• Compact form factor suited for DIN rail mounting in control panels and enclosures
• Supplementary protector design for downstream load protection
• North America (NA) market variant

Compatibility

Designed as an OEM-style supplementary protector for use in industrial control panels and equipment assemblies requiring single-pole, 16-amp overcurrent protection with a C-curve trip characteristic.

Installation Notes

Installation should be performed by a qualified electrician in accordance with the National Electrical Code (NEC) and applicable local codes. De-energize the panel and verify absence of voltage before installing or removing this device. Supplementary protectors must be installed downstream of a branch circuit overcurrent protective device — they are not a substitute for branch circuit protection. Confirm that the enclosure and DIN rail assembly are rated for the application before mounting.

Technical Specifications

• Current Rating: 16 amps
• Poles: 1
• Trip Curve: C-curve
• Device Type: Supplementary Protector
• Market: North America (NA)
• UPC: 01508163635

Standard Information

• Brand: EATON
• Manufacturer Part Number: FAZ-C16/1-NA-SP
