Eaton FAZ-C13/1-NA-L-SP FAZ Branch Protector 13 A

Product Description

The EATON FAZ-C13/1-NA-L-SP is a FAZ branch protector, and UL 489 industrial miniature circuit breaker. Suitable for applications where medium levels of inrush current are expected. It has a current limiting design that provides fast short-circuit interruption, offering superior protection by reducing peak let-through current.

• UL 489 Industrial miniature circuit breaker - supplementary protector
• Single package
• Suitable for applications where medium levels of inrush current are expected

Product Highlights

The EATON FAZ-C13/1-NA-L-SP branch protector is ideal for providing protection in many applications.

Product Information

Standard Information

• Brand: EATON
• Manufacturer Part Number: FAZ-C13/1-NA-L-SP
• Country of Origin: US

Technical Specifications

• Product Name: Eaton FAZ branch protector
• Catalog Number: FAZ-C13/1-NA-L-SP
• EAN: 9010238093393
• Product Length/Depth: 4 in
• Product Height: 3 in
• Product Width: 0.75 in
• Certifications: UL 489
• Product Type: Branch protector
• Auxiliary switch: None
• Mounting Method: DIN Rail
• Number of poles: Single-pole
• Terminals: Screw
• Type: UL 489 Industrial miniature circuit breaker - supplementary protector
• Amperage Rating: 13 A
• Circuit protection: C curve
• Frequency rating: 50-60 Hz
• Interrupt rating: 10 kAIC
• Trip rating: 13 A
• Voltage rating: 277V
• Application: Suitable for applications where medium levels of inrush current are expected
• Quantity: 1
• Special features: Single package
• Category: Circuit Protection
• Current Rating (Amps): 13A
• Manufacturer: Eaton Electrical
• Voltage Rating - AC: 277 V
• Series: FAZ Series
• Actuator Type: Lever
• Packaging: Bulk
• Number of Poles: 1 Pole
• Part Status: Active
• Illumination: None
• Approval Agency: UL489
• Breaker Type: Thermal Magnetic
• Brand: Eaton - Cutler Hammer
• Characteristic: C Curve
• Current Rating: 13 A
• Manufacturer Part Number: FAZ-C13/1-NA-L-SP
• Mounting Type: DIN Rail Mount
• Connection Type: Screw
• Frequency Rating: 50 to 60
• Dimensions: 3 in H x 0.75 in W x 4 in L
• Breaker Amperage Rating: 13 Amp
• Breaker Number of Poles: Single Pole
• Breaker Voltage Rating: 277 VAC
• Breaker UL Rating: UL 489
• Component: Miniature Circuit Breaker
• Breaker Overcurrent Protection Rating: 10 Ka
• Breaker Trip Speed: C Curve
• Model: FAZ C 13 1 NA SP
• MPN: FAZ-C13 1 NA SP
