Eaton FAZ-C10/2-NA FAZ-NA UL 489 MCB 10A 2 Pole 277/480V

Product Description

The Eaton FAZ-C10/2-NA is a UL 489 Industrial miniature circuit breaker designed for branch protection. This two-pole device can handle a voltage rating of two hundred seventy-seven to four hundred eighty volts and is rated for ten amps. It provides important protection against electrical overload and short circuits.

• Voltage Rating: 277/480V
• Amperage Rating: 10A
• Interrupt Rating: 10 kAIC, 14 kAIC

Product Highlights

This breaker is suitable for applications requiring reliable circuit protection. It is ideal for renewable energy systems, conventional energy generation, and data center installations.

Product Information

Standard Information

• Catalog Number: FAZ-C10/2-NA
• Brand: Eaton

Technical Specifications

• Number of Poles: 2
• Type: Branch protector
• Trip Type: 5-10X
• Frequency Rating: 50-60 Hz
• Country of Origin: Spain
• Dimensions: 3 inches x 1.5 inches x 4.25 inches
• Weight: 0.6 lb
• Standards: UL 489, CSA Std. C22.2 No. 235
