Eaton FAZ-C10/2 FAZ UL 1077 10A 2 Pole

Product Description

Eaton FAZ-C10/2 is a supplementary protector designed to provide safety in various applications. It is a dual-rated industrial miniature circuit breaker. The device has a trip type of 5-10X and operates at a frequency of fifty to sixty hertz. This breaker is suitable for medium levels of inrush current.

• Two-pole configuration
• Rated for ten amps with an interrupt capacity of fifteen kAIC
• Standard terminal type for easy installation

Product Highlights

The Eaton FAZ-C10/2 is built for exceptional reliability in power distribution and circuit protection. It is ideal for use in renewable energy applications, marine vessels, and datacenters.

Product Information

Standard Information

• Brand: Eaton
• Manufacturer: Cutler-Hammer/Eaton

Technical Specifications

• Catalog Number: FAZ-C10/2
• Amperage Rating: 10 A
• Voltage Rating: 480Y/277 VAC
• Interrupt Rating: 15 kAIC
• Number of Poles: 2
• Frequency Rating: 50-60 Hz
• Standards: CSA Std. C22.2 No.235, UL 1077
• Country of Origin: Romania
