Eaton FAZ-C1.5/2-NA ETN FAZ-C15/2-NA FAZ-NA UL 489 MCB 15 Amp 2 Pole

Product Description

The Eaton FAZ-C1.5/2-NA is a UL 489 Industrial Miniature Circuit Breaker designed for circuit protection. This two-pole breaker operates at a voltage rating of two hundred seventy-seven to four hundred eighty volts with a current rating of fifteen amps. It features a current limiting design and fast short-circuit interruption to enhance safety.

• Dual-rated UL and IEC certification for various applications.
• Capable of handling inrush currents up to 10 kAIC.
• Built with screw terminals for reliable connections.

Product Highlights

The Eaton FAZ-C1.5/2-NA offers reliable circuit protection and safety. It supports various applications from marine equipment to IT infrastructures.

Product Information

Standard Information

• Brand: Eaton
• Manufacturer: Cutler-Hammer / Eaton

Technical Specifications

• Catalog Number: FAZ-C15/2-NA
• Voltage: 277/480 Volt
• Amperage: 15 Amp
• Number of Poles: 2 Pole
• Trip Type: 5-10X
• Interrupt Rating: 10 kA, 14 kA
• Dimensions: 1.4 in L x 2.97 in W x 4.13 in H
• Temperature Rating: -25 to 75 degrees C
• Standards: UL 489, CSA Std. C22.2 No. 235
• Country of Origin: Spain
