Eaton FAZ-C0.5/1-SP Faz-c0.5/1-sp 0.5 A Single Pkg

Product Description

The EATON FAZ-C0.5/1-SP supplementary protector is a UL 1077 recognized DIN rail mounted miniature circuit breaker with a 0.5 A amperage rating. Suitable for appliances, business equipment, and industrial applications, it provides reliable circuit protection. It has a 277 VAC, 48 VDC voltage rating and a 50/60 Hz frequency rating.

• Current limiting design provides fast short-circuit interruption.
• Features thermal magnetic over current protection.
• Trip-free design prevents breaker from being defeated by holding the handle in the On position.

Product Highlights

This supplementary protector offers reliable overcurrent protection with a convenient DIN rail mounting design.

Product Information

Standard Information

• Brand: EATON
• Manufacturer Part Number: FAZ-C0.5/1-SP

Technical Specifications

• Amperage Rating: 0.5 A
• Application: Appliances, Business Equipment, Control Circuits, Circuit Protection, Lighting, Supplementary Protection, Industrial, Conventional Energy Generation, Renewable Energy and Alternative Energy Generation, Datacenters, IT Space - CI, Hyper Converged, Marine Vessels and Equipment Applications
• Connection Type: Line/Load Side Standard Terminal
• Enclosure: IP20
• Frequency Rating: 50/60 Hz
• Manufacturer Part Number: FAZ-C0.5/1-SP
• Material: Nylon
• Mounting Type: DIN Rail
• Number of Poles: 1
• Series: FAZ-NA
• Standards/Approvals: CCC Certified|CE Marking|CSA C22.2 No. 235|IEC 60947-2|UL 1077|VDE Certified
• Temperature Rating: -40 to 167 deg F
• Trip Type: 5-10X/C-Curve
• Voltage Rating: 277 VAC, 48 VDC
• Product Length/Depth: 0.69 in
• Product Height: 0.69 in
• Product Width: 1 in
• Product Type: Supplementary protector
• Terminals: Standard
• Type: UL 1077 Industrial miniature circuit breaker - supplementary protector
• Circuit protection: C curve
• Interrupt rating: 15 kAIC
• Special features: Single package
• Brand: Eaton / Cutler-Hammer
• Part Number: FAZ-C0.5/1-NA-SP
• Amperage: 0.5A
• Poles: 1
• Phase: 1
• AIC Rating: 10kA @ 277VAC, 10kA @ 48VDC
• Terminal Type: Screw
• For Use With: DIN Rail Systems, Industrial Control Panels
• Trip Technology: Thermal Magnetic
• Trip Function Code: LI
• Trip Function: Long-Time, Instantaneous
• Trip Curve: C
• Trip Adjustability: Fixed
• Wire Gauge: 18-6 AWG (1 wire), 18-10 AWG (2 wires)
• Max Wire: 6 AWG
• Min Wire: 18 AWG
• Available Options: Auxiliary Switch, Shunt Trip, Undervoltage Release, Lockout Attachment, Busbar System
• Accessories: Auxiliary Switch, Busbar System, Lockout Attachment, Shunt Trip, Undervoltage Release
• Standards: CSA C22.2 No. 5, IEC 60947-2, UL 489
• Approval: ABS, CCC, CE, CSA, DNV, IEC, Lloyd's, RoHS, UL, VDE
• Temp Rating: -40C to 75C
• Construction Features: Current Limiting, HACR Rated, Reverse Feed, Trip-Free Mechanism, Visual Trip Indicator
• Manufacturer: Klockner-Moeller, Div of Eaton Corp.
• Product Series: FAZ
• Family Series: Klockner-Moeller, Div of Eaton Corp. Circuit Breakers, FAZ Series
• Current Rating: 0.5 A
• Max Voltage: 277 VAC, 48 VDC
• Trip Unit: Fixed Thermal / Fixed Magnetic
• Mounting: DIN Rail
• Neutral Pole: No
• Auxiliary Switch: Optional
• Shunt Trip: Optional
• Undervoltage Release: Optional
• Alarm Switch: Optional
• UL Standard: 1077
• Approvals: CCC, CSA, UL, VDE
• Net Weight: 0.245 lbs
• Gross Weight: 0.27 lbs
