Eaton FAZ-C0.5/1-NA-SP FAZ-C0,5/1-NA- 0.5 A (Single Pack) Replacement MPN

Product Description

The Eaton FAZ-C0.5/1-NA-SP is a branch protector designed for use in various electrical applications. This UL 489 industrial miniature circuit breaker serves as a supplementary protector. It is suitable for applications with medium inrush current levels.

• Integrates easily with screw terminals for quick installation.
• Features a single-pole design rated at zero point five amps.
• Capable of handling up to ten kA interrupting current.

Product Highlights

The Eaton FAZ-C0.5/1-NA-SP ensures safety and reliability in electrical systems, providing essential protection against overloads and short circuits.

Product Information

Standard Information

• Brand: Eaton
• MPN: FAZ-C0.5/1-NA-SP

Technical Specifications

• Catalog Number: FAZ-C0.5/1-NA-SP
• Type: Standard Current Limiting
• Voltage Rating: 277 V
• Amperage Rating: 0.5 Amp
• Number of Poles: 1
• Frequency Rating: 50-60 Hz
• Interrupt Rating: 10 kAIC
• Trip Type: 5-10X
