Eaton FAZ-B10/1N Current Limiting Circuit Breaker 10A

Product Description

The EATON FAZ-B10/1N is a current limiting circuit breaker rated at 10 amps with a 1-pole configuration. Current limiting breakers are designed to reduce the let-through energy during a fault event, providing enhanced protection for downstream components, wiring, and equipment. This type of device is commonly installed in panelboards, load centers, and control panels where fast-acting overcurrent protection is required. Licensed electricians and panel technicians install this breaker in commercial and industrial applications where system coordination and equipment protection are critical priorities.

The FAZ-B10/1N is suited for branch circuit and supplementary protection in applications requiring compact, high-performance overcurrent protection. Its B-curve trip characteristic makes it appropriate for resistive loads and light inductive loads where nuisance tripping must be minimized. This breaker is typically found in control panels, machine tool enclosures, and similar installations where space-efficient, reliable circuit protection is essential.

Key Features

• Current limiting design reduces let-through energy during fault conditions
• 10 amp continuous current rating
• 1-pole configuration for single-phase branch circuit protection
• B-curve trip characteristic suited for resistive and light inductive loads
• Compact form factor appropriate for panelboards and control enclosures

Compatibility

Designed as an OEM-style replacement or upgrade circuit breaker for compatible EATON FAZ-series panelboards and control panel installations requiring a 10 amp, 1-pole current limiting breaker with a B-trip curve.

Installation Notes

Installation must be performed by a licensed electrician in accordance with the National Electrical Code (NEC) and all applicable local codes. De-energize and lock out the panel before removing or installing any circuit breaker. Verify that the breaker voltage and interrupt ratings are appropriate for the installation before energizing. Do not exceed the breaker's rated current or apply it to loads outside its intended trip curve classification.

Technical Specifications

• Current Rating: 10 amps
• Number of Poles: 1
• Trip Curve: B
• Type: Current Limiting Circuit Breaker
• UPC: 01508278644

Standard Information

• Brand: EATON
• Manufacturer Part Number: FAZ-B10/1N
