Eaton FAZ-B10/1-NA FAZ Branch Protector 10 A

Product Description

The EATON FAZ-B10/1-NA is a FAZ branch protector, which is a UL 489 industrial miniature circuit breaker. It is a supplementary protector suitable for applications where low levels of inrush current are expected. It has a 10 A amperage rating and is a single-pole breaker with screw terminals.

• UL 489 Industrial miniature circuit breaker - supplementary protector
• Low levels of inrush current are expected
• Suitable for applications where low levels of inrush current are expected

Product Highlights

EATON FAZ-B10/1-NA branch protector is ideal for use in branch service applications. It provides reliable protection for personnel, installations, and plant equipment.

Product Information

Standard Information

• Brand: EATON
• Manufacturer Part Number: FAZ-B10/1-NA

Technical Specifications

• Product Name: Eaton FAZ branch protector
• Catalog Number: FAZ-B10/1-NA
• EAN: 4015081296323
• Product Length/Depth: 0.75 in
• Product Height: 3 in
• Product Width: 4 in
• Certifications: UL 489 CSA Std. C22.2 No. 235
• Product Type: Branch protector
• Number of poles: Single-pole
• Terminals: Screw
• Type: UL 489 Industrial miniature circuit breaker - supplementary protector
• Amperage Rating: 10 A
• Circuit protection: B curve
• Frequency rating: 50-60 Hz
• Interrupt rating: 14 kAIC 10 kAIC
• Trip Type: 3-5X /n
• Voltage rating: 277/480V
• Application: Suitable for applications where low levels of inrush current are expected
• Mounting Method: DIN Rail
• Voltage Rating - AC: 277 V
• Voltage Rating - DC: 48 V
• Series: FAZ-NA
• Actuator Type: Lever
• Breaker Type: Thermal Magnetic
• Approval Agency: ABS, CCC, CSA C22.2 No 235, IEC 60947-2, UL489, VDE
• Connection Type: Screw/Standard Terminal
• Temperature Rating: 40 deg C
• Wire Size: 18 to 6 AWG
• Interrupt Rating: 14 kA
• Current Rating: 10 A
• Characteristic: B Curve
• Dimensions: 3/4 x 4 x 3 in
