Eaton EHD3090L C-H Series C NEMA F-Frame Molded Case Circuit Breaker 90 A

EATON
Brand: EATON
SKU: EHD3090L
Availability: In Stock

Ships same day if ordered by 12 pm

%3Cp%3EEarn%20[points_amount]%20when%20you%20buy%20this%20item.%3C/p%3E
$1,333.32
$1,333.32
HAVE A QUESTION?

Our team is ready to help!

215-326-9845
  • Voomi Supply

    Secure Payments

  • Voomi Supply

    Easy Returns

  • Voomi Supply

    Expert Advice

  • Voomi Supply

    Fast Shipping

Description

Product Description

The EATON EHD3090L molded case circuit breaker is a Type EHD, C Series, operating at 480 VAC/250 VDC and 90 A with a frequency of 50/60 Hz. It features a 14 kAIC at 480 VAC/18 kAIC at 240 VAC interrupt rating, an F Frame, and a fixed thermal/fixed magnetic trip. This 3-pole breaker is suitable for panelboards, switchboards, motor control centers, busways, electrical assemblies and OEMs applications.

  • Patented contact design features high speed "blow-open" action, resulting in superior performance
  • Suitable for reverse feed applications
  • 18 kA at 240 VAC, 14 kA at 480 VAC interrupt rating

Product Highlights

The EATON EHD3090L circuit breaker offers reliable circuit protection with a fixed thermal/fixed magnetic trip and is suitable for various applications.

Product Information

Standard Information

  • Brand: EATON
  • Manufacturer Part Number: EHD3090L
  • Country of Origin: United States

Technical Specifications

  • Actuator Type: Handle
  • Amperage Rating: 90 A
  • Application: Panelboard, Switchboard, Motor Control Center, Busway, Electrical Assemblies and OEMs Applications
  • Connection Type: Line/Load
  • Frame: F
  • Frequency Rating: 50/60 Hz
  • Manufacturer Part Number: EHD3090L
  • Number of Poles: 3
  • Series: C Series
  • Standards/Approvals: AS 2184|BS 4752|CSA C22.2/5|Federal Specification WC-375B|HACR Rated|IEC 60947-2|SABS 156|SEV 157-1|UL 489|VDE 0660
  • Temperature Rating: 40 deg C
  • Trip Type: T186
  • Type: Type EHD
  • Voltage Rating: 480 VAC/250 VDC
  • Product Length/Depth: 3.38 in
  • Product Height: 6 in
  • Product Width: 4.13 in
  • Certifications: UL Listed
  • Product Type: Molded case circuit breaker
  • Circuit breaker type: EHD
  • Circuit breaker frame type: Complete breaker
  • Terminals: Line and load
  • Interrupt rating: 14 kAIC at 480 Vac 18 kAIC at 240 Vac
  • Product Name: Eaton Series C complete molded case circuit breaker
  • UPC: 786679399729
  • Brand: EATON
  • Condition: New
  • Category: Business & Industrial>Electrical Equipment & Supplies>Circuit Breakers & Disconnectors>Circuit Breakers
  • Country of Origin: United States
