Eaton EHD3080 Series C F Frame Molded Case Circuit Breaker 80 A

Product Description

The Eaton EHD3080 Series C F Frame Molded Case Circuit Breaker is designed to provide reliable circuit protection. This molded case circuit breaker has a fixed thermal and magnetic trip type. It features three poles and a current rating of 80 Amps, suitable for both 50 and 60 Hertz applications. It is ideal for use in panelboards, switchboards, motor control centers, and busway applications.

• Current Rating: 80 A
• Number of Poles: 3
• Frame Type: F

Product Highlights

This breaker ensures efficient performance in various electrical applications and meets notable industry standards.

Product Information

Standard Information

• Manufacturer: Eaton
• Trip Type: Fixed Thermal, Fixed Magnetic

Technical Specifications

• Catalog Number: EHD3080
• Amperage: 80 A
• Frequency: 50/60 Hz
• Interrupt Rating: 18 kAIC at 240 Vac | 14 kAIC at 480 Vac
• Country of Origin: Dominican Republic
• Item Type: Molded Case Circuit Breaker
• Frame: F
• Dimensions: 3.38 x 4.13 x 6 inches
