EATON EHD3060 Breaker Ckt Case Mld 480 VAC/250 VDC 60A

Product Description

The Eaton EHD3060 is a molded case circuit breaker with a voltage rating of 480 VAC/250 VDC and an amperage rating of 60 A. Designed for various applications such as panelboards, switchboards, and motor control centers, it assures efficient circuit protection. This breaker features a fixed thermal and fixed magnetic trip, offering reliable performance in critical environments.

• Type EHD Complete, F Frame design
• Interrupt rating of 14/18 kA
• Three poles for enhanced circuit management

Product Highlights

This breaker is suitable for low voltage distribution, ensuring safety and performance. It is UL listed, confirming it meets stringent North American safety standards.

Product Information

Standard Information

• Brand: Eaton
• Model No.: EHD3060

Technical Specifications

• Voltage Rating: 480 VAC/250 VDC
• Current Rating: 60 A
• Number of Poles: 3
• Frequency Rating: 50/60 Hz
• Interrupt Rating: 14 kA at 480 VAC, 18 kA at 240 VAC
• Trip Type: Fixed Thermal/Fixed Magnetic
• Dimensions: 3.38 inches L x 4.13 inches W x 6 inches H
• Material: Glass Polyester
• Weight: 4.5 lb
• Country of Origin: Dominican Republic
