Eaton EHD3045L C Series Type EHD Molded Case Circuit Breaker 480 VAC/250 VDC 45 A 14 kAIC at 480 VAC/18 kAIC at 240 VAC Interrupt 3 Poles

Product Description

Eaton EHD3045L is a molded case circuit breaker designed for effective circuit protection in various applications. It features a three-pole configuration with a current rating of forty-five amperes and is suitable for use with systems up to six hundred volts alternating current and two hundred fifty volts direct current. This breaker meets industry standards for safety and performance.

• Current Rating: 45 Amperes
• Interrupt Rating: 14 kAIC at 480 VAC
• Trip Type: Fixed Thermal/Fixed Magnetic

Product Highlights

This circuit breaker provides reliable performance in panelboards, switchboards, and motor control centers.

Product Information

Standard Information

• Brand: Eaton
• MPN: EHD3045L

Technical Specifications

• Type: Molded case circuit breaker
• Frame: F
• Voltage Rating: 480 VAC/250 VDC
• Frequency Rating: 50/60 Hz
• Number of Poles: 3
• Dimensions: 3.38 x 4.13 x 6 inches
• Weight: 4 lbs
• Applications: Electrical Assemblies, Panels, and EOEM
• Interrupt Rating: 14 kAIC at 480 VAC | 18 kAIC at 240 VAC
