Eaton EHD3040 series C F Frame molded case circuit breaker 480 VAC 250 VDC

Product Description

The Eaton EHD3040 series C molded case circuit breaker is designed for use in various electrical applications. This unit operates at 480 VAC and 250 VDC with a current rating of forty amps. It features three poles and is suitable for panelboards, switchboards, motor control centers, and busway applications.

• Type: Molded case circuit breaker
• Current Rating: 40 Amp
• Number of Poles: 3

Product Highlights

This breaker includes fixed thermal and magnetic trip types for reliable protection in electrical systems. Ideal for both commercial and industrial uses.

Product Information

Standard Information

• Manufacturer: Eaton
• Brand: Eaton

Technical Specifications

• Frame: F
• Frequency Rating: 50/60 Hz
• Interrupt Rating: 18 kAIC at 240 Vac | 14 kAIC at 480 Vac
• Application: Electrical Assemblies, Panels & EOEM
• Dimensions: 3.38 x 4.13 x 6 inches
• UPC: 786679317129
• GTIN: 00786679317129
• Country of Origin: Dominican Republic
• Made in USA: No
