Eaton EHD3035L Molded Case Circuit Breaker 35 A

Product Description

The EATON EHD3035L series C molded case circuit breakers are used in panelboard, switchboard, motor control center and busway applications for dependable branch circuit protection. Suitable for systems up to 600 VAC/250 VDC with current ratings up to 2500 A.

• Patented contact design features high speed "blow-open" action, resulting in superior performance
• Suitable for reverse feed applications
• 18 kA at 240 VAC, 14 kA at 480 VAC interrupt rating

Product Highlights

EATON EHD3035L is a molded case circuit breaker with fixed thermal/fixed magnetic trip, handle actuator and line/load connection.

Product Information

Standard Information

• Brand: EATON
• Manufacturer Part Number: EHD3035L
• Country of Origin: US

Technical Specifications

• Actuator Type: Handle
• Connection Type: Line/Load
• Frame: F
• Frequency Rating: 50/60 Hz
• Series: C Series
• Temperature Rating: 40 deg C
• Type: Type EHD
• Voltage Rating: 480 VAC/250 VDC
• Amperage Rating: 35 A
• Interrupt Rating: 14 kAIC at 480 VAC/18 kAIC at 240 VAC
• Number of Poles: 3
• Trip Type: Fixed Thermal/Fixed Magnetic
• Name: Circuit Breaker
