Eaton EHD3010L Series C Molded Case Circuit Breaker 10A

Product Description

The EATON EHD3010L is a Series C complete molded case circuit breaker. This three-pole breaker features fixed thermal, fixed magnetic trip type, and is rated for 10A. Suitable for panelboard, switchboard, motor control center and busway applications for dependable branch circuit protection. Frequency rating 50/60 Hz.

• Patented contact design features high speed "blow-open" action, resulting in superior performance
• Suitable for reverse feed applications
• 18 kA at 240 VAC, 14 kA at 480 VAC interrupt rating

Product Highlights

Eaton EHD3010L circuit breakers provide dependable branch circuit protection in various applications. They meet or exceed North American standards.

Product Information

Standard Information

• Brand: EATON
• Manufacturer Part Number: EHD3010L

Technical Specifications

• Product Name: Eaton Series C complete molded case circuit breaker
• Catalog Number: EHD3010L
• UPC: 786679317020
• Product Length/Depth: 3.38 in
• Product Height: 6 in
• Product Width: 4.13 in
• Certifications: UL Listed
• Product Type: Molded case circuit breaker
• Amperage Rating: 10 A
• Trip Type: Fixed Thermal/Fixed Magnetic
• Circuit breaker type: EHD
• Circuit breaker frame type: Complete breaker
• Series: Series C
• Terminals: Line and load
• Frame: F
• Frequency rating: 50/60 Hz
• Interrupt rating: 14 kAIC at 480 Vac 18 kAIC at 240 Vac
• Number of poles: Three-pole
• UNSPSC: 39121616
• Application: Panelboard, Switchboard, Motor Control Center, Busway, Electrical Assemblies and OEMs Applications
• Voltage Rating: 480 V
• Connection Type: Line/Load
• Temperature Rating: 40
• Type: Type EHD
• Actuator Type: Handle
• UNSPSC Code: 39120000
• Brand: Eaton - Cutler Hammer
• Current Rating: 10 A
• Frame Type: FD Frame
• Weight: 4.15 lb
• Dimensions: 3.38 x 4.13 x 6
