Eaton EHD1040L Type Ehd Brk 1P 40A 27

Product Description

The Eaton EHD1040L is a series C complete molded case circuit breaker with an F-frame, designed with fixed thermal and fixed magnetic trip types. This single-pole, 40A breaker offers dependable branch circuit protection for panelboard, switchboard, motor control center, and busway applications. It operates at 50/60 Hz.

• Fixed thermal, fixed magnetic trip type
• Suitable for reverse feed applications
• Patented contact design features high speed blow-open action

Product Highlights

Eaton's EHD1040L circuit breaker is designed for electrical and machinery OEMs, offering innovation and high reliability.

Product Information

Standard Information

• Brand: EATON
• Manufacturer Part Number: EHD1040L
• Country of Origin: United States

Technical Specifications

• Catalog Number: EHD1040L
• Type: Molded case circuit breaker
• Brand: Eaton
• Frame: F
• Height: 6 Inch
• Length: 3.38 Inch
• Current: 40 Amp
• Amperage: 40 Amp
• Frequency: 50 Hz
• Trip Type: T186
• Product UPC: 78667939836
• 12-Digit UPC: 786679398364
• Applications: Elec Assemblies, Panels & EOEM - Electrical Assemblies and EOEMs - Other
• Terminal Type: Line And Load
• Number of Poles: 1 Pole
• Interrupt Rating: 14 kAIC
• Product Name: Eaton Series C complete molded case circuit breaker
• Product Length/Depth: 3.38 in
• Product Width: 1.38 in
• Certifications: UL Listed
• Product Type: Molded case circuit breaker
• Amperage Rating: 40 A
• Circuit breaker type: EHD
• Circuit breaker frame type: Complete breaker
• Series: Series C
• Terminals: Line and load
• Frequency rating: 50/60 Hz
• Interrupt rating: 14 kAIC at 480 Vac 18 kAIC at 240 Vac
• Number of poles: Single-pole
• Part Number: EHD1040L
• Manufacturer: Eaton Cutler-Hammer
• Family: Series C
• Pole: 1
• Amp: 40
• Volt: 277
• Phase: 1
• Connection: Feed-Thru
• Functions: LI - Long-Time and Instantaneous
• Protection: Thermal Magnetic
• AIC Ratings: 14kA@480V
• Frame Type: F Frame
• Dimensions (HxWxD): 6" x 1.38" x 3.38"
• Voltage Rating: 277 VAC/125 VDC
• Connection Type: Line/Load
• Temperature Rating: 40
• UNSPSC: 39121616
• Condition: New
• Poles: 1
• Mounting: Bolt-On
• Current Rating: 40 A
• Trip Unit: Fixed Thermal / Fixed Magnetic
• Gross Weight: 1.75 lbs
• Net Weight: 1.75 lbs
• Amperage (Molded Case Breaker): 40 Amp
• Poles (Molded Case Breaker): Single Pole
• Maximum Voltage (Molded Case Breaker): 480 VAC
• Component: Molded Case Circuit Breaker
• Frame Type (Molded Case Breaker): F Frame
• Interrupt Rating (Molded Case Breaker): 18 Ka 240 Volt
• UL Listing (Molded Case Breaker): UL Listed
• Country of Origin: United States
• Amps: 40A
• Voltage: 277VAC
