Eaton EHD1030L EHD 1030L 1P 30A

Product Description

The Eaton EHD1030L is a Series C complete molded case circuit breaker with an F-frame, designed for dependable branch circuit protection. This single-pole, 30A breaker features a fixed thermal, fixed magnetic trip type. It is rated 18 kAIC at 240 Vac and 14 kAIC at 480 Vac, suitable for line and load applications at 50/60 Hz.

• Fixed thermal, fixed magnetic trip type
• Line and load terminals
• Suitable for panelboard, switchboard, motor control center, and busway applications

Product Highlights

Eaton’s Series C MCCBs provide reliable circuit protection with a robust design and are suitable for various commercial applications.

Product Information

Standard Information

• Brand: EATON
• Manufacturer Part Number: EHD1030L
• Country of Origin: United States

Technical Specifications

• Type: Molded case circuit breaker
• Brand: Eaton / Cutler-Hammer
• Frame: F
• Width: 1.38 in
• Height: 6 Inch
• Length: 3.38 Inch
• Current: 30 Amp
• Amperage: 30A
• Frequency: 50/60 Hz
• Trip Type: Thermal/Magnetic
• Product UPC: 78667915680
• 12-Digit UPC: 786679156803
• Applications: Elec Assemblies, Panels & EOEM - Electrical Assemblies and EOEMs - Other
• Terminal Type: Line and load
• Number of Poles: 1 Pole
• Interrupt Rating: 14 kAIC
• Product Name: Eaton Series C complete molded case circuit breaker
• Catalog Number: EHD1030L
• Product Length/Depth: 3.38 in
• Product Height: 6 in
• Product Width: 1.38 in
• Certifications: UL Listed
• Product Type: Molded case circuit breaker
• Amperage Rating: 30 A
• Circuit breaker type: EHD
• Circuit breaker frame type: Complete breaker
• Series: EHD
• Interrupt rating: 14 kAIC at 480 Vac 18 kAIC at 240 Vac
• Part Number: EHD1030L
• Voltage: 277VAC, 125VDC
• Poles: 1
• Phase: 1
• AIC Rating: 14kA @ 277VAC, 10kA @ 125VDC
• Mounting Style: Unit Mount
• For Use With: Eaton Series C Panelboards, Switchboards, Enclosures
• Trip Technology: Thermal Magnetic
• Trip Function Code: LI
• Trip Function: Long-Time, Instantaneous
• Trip Adjustability: Fixed Thermal, Fixed Magnetic
• Wire Gauge: 14-1/0 AWG
• Max Wire: 1/0 AWG
• Min Wire: 14 AWG
• Available Options: Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch, Padlock Attachment, Motor Operator
• Accessories: Line and Load Lugs
• Standards: CSA C22.2 No. 5, NEMA AB 1, UL 489
• Approval: CSA, UL
• Temp Rating: 40C
• Construction Features: HACR Rated, HID Rated, Reverse Feed, Non-Interchangeable Trip, Trip-Free Mechanism, Quick-Make/Quick-Break
• Mounting: Panel
• Volts AC: 277
• Volts DC: 125
• Amps: 30
• Interrupt Rating AC: 14 kA
• UNSPSC Code: 39120000
• Current Rating: 30 A
• Manufacturer Part Number: EHD1030L
• c Series: c Series
