Eaton EHD1020L Series C F Frame Molded Case Circuit Breaker 20 Amp REPLACEMENT FDB1020L

Product Description

The Eaton EHD1020L Series C complete molded case circuit breaker, F-frame, EHD, is a complete breaker with fixed thermal and magnetic trip types. This single-pole, 20A circuit breaker has an interrupt rating of 18 kAIC at 240 Vac and 14 kAIC at 480 Vac, and operates at 50/60 Hz. It is designed for line and load applications.

• Complete molded case circuit breaker
• Fixed thermal trip type
• Fixed magnetic trip type

Product Highlights

The Eaton EHD1020L circuit breaker provides dependable branch circuit protection in panelboard, switchboard, motor control center, and busway applications.

Product Information

Standard Information

• Brand: EATON
• Manufacturer Part Number: EHD1020L
• Country of Origin: DOM

Technical Specifications

• Type: Molded case circuit breaker
• Brand: Eaton / Cutler-Hammer
• Frame: F
• Width: 1.38 in
• Height: 6 Inch
• Length: 1.25
• Current: 20 Amp
• Amperage: 20 A
• Standard: UL
• Frequency: 50/60 Hz
• Trip Type: Fixed Magnetic,Fixed Thermal
• Max Voltage: 480 V
• Product UPC: 78667915670
• 12-Digit UPC: 786679156704
• Applications: Elec Assemblies, Panels & EOEM - Electrical Assemblies and EOEMs - Other
• Terminal Type: Lugs
• Product Series: C
• Number of Poles: 1
• Interrupt Rating: 14 kAIC
• Circuit Breaker Type: EHD
• Actuator Type: Handle
• Connection Type: Line/Load
• Dimensions: 3.38 in L x 1.38 in W x 6 in H
• Enclosure Type: NEMA AB1-1993
• Mounting Type: Panel
• Phase: 1
• Series: C Series
• Temperature Rating: 40 deg C
• Voltage Rating: 277 VAC/125 VDC
• AIC Rating: 14kA @ 277VAC, 10kA @ 125VDC
• Mounting Style: Bolt-On
• Poles: 1
• For Use With: Eaton Series C Enclosures, Control Panels
• Trip Technology: Thermal Magnetic
• Trip Function Code: LI
• Trip Function: Long-Time, Instantaneous
• Trip Adjustability: Fixed Thermal, Fixed Magnetic
• Wire Gauge: 14-1/0 AWG
• Max Wire: 1/0 AWG
• Min Wire: 14 AWG
• Available Options: Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch, Padlock Attachment
• Accessories: Line and Load Lugs
• Standards: CSA C22.2 No. 5, NEMA AB 1, UL 489
• Approval: CSA, HACR, HID, SWD, UL
• Temp Rating: 40C
• Construction Features: HACR Rated, HID Rated, Reverse Feed, Non-Interchangeable Trip
• UNSPSC: 39121616
• Product Length/Depth: 3.38 in
• Product Height: 6 in
• Product Width: 1.38 in
• Certifications: UL Listed
• Maximum Amperage: 20 A
• Number of Phases: 1
• Current Rating: 16-30 A
• Material: Plastic, ABS/Plastic
• Model: EHD1020L
• Item Height: 3.75
• Number of Throws: 1
• Suitable For: Interior, Exterior
• Current Type: AC
• Control Style: Switch
• Number in Pack: 1
• Features: Thermal Overload Protection
• Protection Properties: Overload Protection
• Number of Positions: 2
